Product description

Package List:

Important Note:

Please choose correct power supply before place the order. Wrong power supply may damage your equipment!

If you don't know what power supply you should buy, please let us know, we will help you.

How to choose correct power supply?

1.Check Voltage:

Please check the parameter label of your device and check the working voltage. It should be 12V DC, not be lower/higher than 12V DC. Otherwise, your device will not work or be damaged.

2. Check Current:

Check the max current your device will draw. It should be equal to or less than 5A, such as 0.5A, 1A, 1.5A, 2A, 3A, 4A, 5A. Otherwise, your device won’t work well and the power supply will be damaged very soon.

3. Check power input port:

Check the power input port of your device. Its outer diameter should be 5.5mm; inner core diameter should 2.5mm or 2.1mm. Inner core polarity should be"+", exterior polarity should be" - ". Otherwirse, the power supply can't be plugged into your device.

If your device's voltage is 12V DC, the current is less than 5A, the power port is 5.5mm x 2.5mm or 5.5mm x 2.1mm, and the inside polarity is "+", outside polarity is "-", you can choose this 12V 5A power supply. Otherwise, please choose other power supply according to above instructions.

Flame-retardant exterior shell and built-in safeguards to protect against overheat, overload, over-charging, short-circuit provide ultimate protection for you and your devices.

Built-in advanced synchronous rectifier smart chip and EMI filter, convert fluctuating voltage to stable voltage, effectively reduce electromagnetic interference, ensure stable voltage output.

3x 0.75 mm²(18AWG) copper conductors, individual wire insulation and flexible flame -retardant PVC jacket provide you a safe and reliable cable with better conductivity.

Robust casing protects against scratches,bumps, drops, withstands pressure and keeps internal components safe during emergencies enhanced longevity.

Max 5A ouput means it can supply with amperage less than 5A. ---such as 1A, 3A,5A. If your device draws 4A, 4A will be supplied. But if draws more than 5A, only 5A will be supplied.

We especially add a female terminal connector in the package. You can screw wires onto it to power the devices that have no female DC socket. This will greatly expand its applied range.

We suggest the max use of power should be no more than 80% of the full loads, otherwise,the power supply's spanlife will be shortened. We recommend to use 60W PS to power devices less than 48W.
